Name: MAINBOARD (เมนบอร์ด) GIGABYTE GBT TRX50 AERO D (rev.1.1)
SKU: MBD-GBT-TRX50AER1
Availability: InStock

คุณสมบัติ MAINBOARD (TRX50) GIGABYTE TRX50 AERO D

Brand	GIGABYTE
Model	TRX50 AERO D
CPU Support	AMD Socket sTR5, support for: AMD Ryzen™ Threadripper™ PRO 7000 processors / AMD Ryzen™ Threadripper™ 7000 Series processors(Go to GIGABYTE’s website for the latest CPU support list.)
CPU Brand	AMD
Socket	sTR5
Chipset	AMD TRX50
Memory Support	Support for DDR5 7800(O.C.)/7600(O.C.)/7200(O.C.)/7000(O.C)/6800(O.C.)/6400(O.C.)/6000(O.C.)/5600(O.C.)/5200/4800/4400 MT/s ECC Registered memory modules (RDIMM/RDIMM-3DS) 4 x DDR5 DIMM sockets supporting up to 1TB (256 GB single DIMM capacity) of system memory Quad channel memory architecture Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to “Memory Support List” on GIGABYTE’s website for more information.)
Maximum Memory Bus	7800
Graphics	N/A
Multi Graphic Support	N/A
Audio	Realtek® ALC4080 CODEC (rear panel audio) – Support for DTS:X® Ultra – High Definition Audio – 2-channel Realtek® ALC897 CODEC (front panel audio)
Expansion Slots	CPU: – 2 x PCI Express x16 slots, supporting PCIe 5.0 and running at x16 (PCIEX16_1/PCIEX16_2)* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16_1 slot. – 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16(PCIEX16_3)
Maximum PCIe Version	PCIe 5.0
Storage	CPU: – 1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 5.0 x4/x2 SSD support) (M2C_CPU) – 2 x M.2 connectors (Socket 3, M key, type 22110/2280 PCIe 5.0 x4/x2 SSD support) (M2A_CPU/M2B_CPU) – 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2D_CPU)CPU+Chipset: – 8 x SATA 6Gb/s connectors RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, and RAID 10 support for SATA storage devices
M.2 Storage Type Support	NVMe
M.2 Slot	4
USB	CPU: – 3 x USB 3.2 Gen 2 Type-A ports (red) on the back panelChipset+Intel® JHL8540 USB4® controller: – 2 x USB4® USB Type-C® ports on the back panel Chipset: – 1 x USB Type-C® port with USB 3.2 Gen 2×2 support, available through the internal USB header – 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel – 2 x USB 3.2 Gen 1 ports available through the internal USB header CPU+USB 3.2 Gen 1 Hub: – 4 x USB 3.2 Gen 1 ports on the back panel Chipset+USB 2.0 Hub: – 4 x USB 2.0/1.1 ports available through the internal USB headers
Internal I/O Connectors	1 x 24-pin ATX main power connector 2 x 8-pin ATX 12V power connectors 1 x CPU fan header 1 x CPU fan/water cooling pump header 4 x system fan headers 4 x system fan/water cooling pump headers 3 x addressable RGB Gen2 LED strip headers 1 x RGB LED strip header 4 x M.2 Socket 3 connectors 8 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C® header, with USB 3.2 Gen 2×2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x noise detection header 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only) 1 x power button 1 x Clear CMOS button 1 x reset button 1 x reset jumper 2 x temperature sensor headers 1 x Clear CMOS jumper
Back Panel Connectors	1 x Q-Flash Plus button 2 x SMA antenna connectors (2T2R) 1 x DisplayPort In port 1 x USB4® USB Type-C® port (DisplayPort) 1 x USB4® USB Type-C® port 4 x USB 3.2 Gen 2 Type-A ports (red) 4 x USB 3.2 Gen 1 ports 2 x RJ-45 ports 2 x audio jacks
LAN	Marvell® AQtion AQC113C 10GbE LAN chip (10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/100 Mbps) (LAN1) Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) (LAN)
Wireless Data Network	Qualcomm® Wi-Fi 7 QCNCM865 – 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands – BLUETOOTH 5.3 – Support for 11be 320MHz wireless standard(Actual data rate may vary depending on environment and equipment.) Note: Wi-Fi 7 features require Windows 11 SV3 to function properly. (There is no support driver for Windows 10) Wi-Fi 7 channels on 6GHz band availability depends on individual country’s regulations.
Form Factor	E-ATX
H/W Monitoring	Voltage detection Temperature detection Fan speed detection Water cooling flow rate detection Fan fail warning Fan speed control* Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install. Noise detection
BIOS	1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Special Features	Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. Support for Q-Flash Support for Q-Flash Plus
Software Features	Norton® Internet Security (OEM version) LAN bandwidth management software
Operating System Support	Support for Windows 11 64-bit
Package Contents	N/A

เมนบอร์ด TRX50 AERO D ได้รับการออกแบบมาสำหรับผู้สร้างเนื้อหา ผู้ที่ชื่นชอบ และผู้เชี่ยวชาญด้าน AI ด้วยการออกแบบพลังงาน 16+8+4 เฟสดิจิทัลทั้งหมดของตัวควบคุม Infineon multiphase PWM ทำให้ TRX50 AERO D ปลดปล่อยประสิทธิภาพที่โดดเด่นของ CPU AMD Ryzen™ Threadripper™ เจนเนอเรชั่นใหม่ ในขณะเดียวกันก็มอบความเสถียรที่ดีที่สุดภายใต้ภาระงานหนักและความมุ่งมั่น แพลตฟอร์ม HEDT ที่ทรงพลังที่สุดสำหรับผู้สร้าง

จุดเด่นสินค้า
รองรับโปรเซสเซอร์ AMD Ryzen™ Threadripper™ PRO 7000 series/ Ryzen™ Threadripper™ 7000 series
ประสิทธิภาพที่ก้าวล้ำ：โซลูชัน Digital VRM 16+8+4 เฟส
Quad Channel DDR5：4*SMD R-DIMM พร้อมรองรับ AMD EXPO™ และโมดูลหน่วยความจำ Intel® XMP
เสริมความร้อนโดยรวม：เกราะความร้อน VRM ขั้นสูง & ตัวป้องกันความร้อน M.2
เครือข่ายที่รวดเร็วทันใจ: 10GbE + 2.5 GbE Dual LAN และ Wi-Fi 7
