คุณสมบัติ ATX CASE (NP) NZXT H9 FLOW BLACK
| Brand | NZXT |
| Model | H9 Flow (Matte Black) |
| Form Factor | ATX |
| Mainboard Support | Mini ITX, Micro ATX, ATX |
| Material | SGCC Steel, Ultra-clear Tempered Glass, Dark Tinted Tempered Glass (Black only) |
| Power Supply | No Power Supply |
| Front I/O Port | 2 x USB 3.2 Gen 1 Type-A 1 x USB 3.2 Gen 2 Type-C 1 x Headset Audio Jack |
| Fan | Pre-Install Side : 3 x 120mm Rear : 1 x 120mm |
| Cooling Support | Fan Side : 3 x 120mm Top : 3 x 120mm / 2 x 140mm Bottom : 3 x 120mm / 2 x 140mm Rear : 1 x 120mm Filters : All Air IntakesCooling Side : Up to 360mm with Push/Pull Top : Up to 360mm Bottom : Up to 360mm Rear : Up to 120mm |
| Expansion Slot | 7 Slots |
| Drive Bay | 2.5″ : 4+2 3.5″ : 2 |
| Maximum CPU Cooler Height | 165 mm |
| Maximum Liquid Cooling | 360 mm |
| Maximum VGA Length | 435 mm |
| Maximum PSU Length | 200 mm |
| Dimension | (W x D x H) : 46.60 x 29.00 x 49.50 cm |
| Net Weight | 12.10 KG |
| Package Dimension | (W x D x H) : 38.00 x 56.00 x 56.00 cm |
| Gross Weight | 13.90 KG |
| Volume | 119,168.00 cm3 |
GPU Capacity
The H9 Flow has 435mm of GPU clearance, offering room for the latest NVIDIA 40 Series and AMD 7000 Series cards.
Fan Capacity
The H9 Flow has room for 10 fans. With the capacity for 3x120mm fans on the side, 3 x 120mm or 2x140mm on the top and bottom, and 1 x120mm on the rear.
Radiator Capacity
The H9 Flow has room for up to a 360mm radiator on the top, bottom, or side, and up to a 120mm radiator on the rear.
Reference From : nzxt.com
