[WRE6505 v2] WRE6505 V2 WIRELESS AC750 RANGE EXTENDER

SKU : WRE6505 v2 WRE6505 V2 WIRELESS AC750 RANGE EXTENDER WRE6505 v2 Dualband-AC750 (300+433), 1×10/100, 1xRJ-45, Universal Repeater, – AP

System Specifications
Wireless Standard

802.11 a/b/g/n/ac
Wireless Speed

Transmit: 300 Mbps* for 2.4 GHz and 433 Mbps* for 5 GHz
Receive: 300 Mbps* for 2.4 GHz and 433 Mbps* for 5 GHz
WLAN Features

Repeater mode
AP mode
Wi-Fi Protected Setup (WPS)
Wi-Fi Multimedia (WMM)
Auto channel selection
Wireless scheduling
Wireless output power management
MAC address filtering
Coverage setting mode
System Management

Online firmware upgrade
Hardware Specifications
LAN: One 10/100 Mbps Ethernet RJ-45 port
LED indicators:
Power/WPS (Blue)
WLAN (2.4 GHz)(White, one LED-Weak, two LEDs-Good, three LED-Best)
WLAN (5 GHz)(White, one LED-Weak, two LEDs-Good, three LED-Best)
Button: WPS button
Power Input: 100 V to 240 V AC, 50/60 Hz
Physical Specifications
Item dimensions (W x D x H): 54.8 x 45.2 x 77.8 mm (2.16″ x 1.78″ x 3.06″)
Item weight: 88.6 g (0.20 lb.)
Packing dimensions (W x D x H): 138 x 122 x 95 mm (5.43″ x 4.80″ x 3.74″)
Packing weight: 243 g (0.54 lb.)
Environmental Specifications
Operating Environment
Temperature: 0°C to 40°C (32°F to 104°F)
Humidity: 10% to 90% (Non-condensing)
Storage Environment
Temperature: -30°C to 70°C (-22°F to 158°F)
Humidity: 10% to 95% (Non-condensing)
Certification
Safety: CE LVD
EMC: CE, FCC
Package Contents
Wireless range extender
Ethernet cable
Quick start guide
(including form)
